JVM Multithreading: Monitor Locks and Visibility

Mar 14, 2013 • @alexelcu

Multithreading is a bitch to deal with. While interviewing developers, I noticed that surprisingly many don’t have knowledge about this topic and I can’t blame them really. However, in this day and age, for some problem domains building highly-concurrent architectures may be paramount to the success of demanding projects. As you’ll see, there are many high level solutions, but I personally prefer to learn with a bottom up approach, starting from the basic and unsafe primitives, as understanding the problem is always the first step to real solutions.

This is (hopefully) the start of a series of articles giving an overview of the primitives and tools available on top of the JVM for solving concurrency-related problems, with code given in Scala and Java, starting from standard synchronization techniques, going through low-level primitives and non-blocking algorithms based on compare-and-set, up to high-level tools, such as Futures/Promises, actors and optimistic locking with shared transactional memory.

The Problem of Atomicity

Over 100,000 people can watch the same soccer game from the same stadium, at the same time. Those same 100,000 people cannot all take a dump in the same bathroom at the same time. Writing data to a central location requires an agreed-upon protocol for establishing who’s allowed to write and when.

Most of our concurrency-related problems come from our usage of mutable data and data-structures, as both reading and writing are problematic. When updating a mutable data-structure, the data can get into an inconsistent state, so threads that are doing the reading can end-up with garbage. When multiple threads are updating the same data-structure, the result can be far worse as it can lead to irrecoverable data corruption.

To solve the problem, you want updates to seem instantaneous from other threads, with no in-between intermediary and inconsistent state. A piece of code is considered atomic if it seems instantaneous to other threads.

Consider implementing a basic stack. Below is one example in which many things can go wrong, pointing out a few gotchas off the top of my head.

(See here for the Java version)

/**
  * Class representing nodes in a simple linked list.
  *
  * NOTES:
  *
  * 1. considering this class is used in the context of a stack,
  *    we never need to add or remove from the middle, so there's
  *    no reason for why this shouldn't be immutable
  *
  * 2. leaving this class public exposes the internal implementation
  *    of our stack
  *
  */
class Node {
  var value: Any = null
  var next: Node = null
}
/**
  * Totally unsafe, totally screwed implementation of a stack.
  */
class Stack {
  /**
    * Gotcha: leaving our head public, means other threads can mess with
    * the internal state of our stack, even more so because our Node class
    * is mutable.
    */
  var head: Node = null
  def isEmpty = head == null
  def push(value: Any) {
    val node = new Node
    node.value = value
    node.next = this.head
    // Gotcha: by the time we assign the new head, another thread
    // may have changed it already
    this.head = node
  }
  def pop() =
    if (!isEmpty) {
      // Gotchas:
      //
      // 1. by the time the following is executed the `head`
      //    can already be null
      //
      // 2. two or more threads may read the same `head` and
      //    thus receive the same value on pop()
      val node = this.head
      // 1. again, the `head` can already be different,
      //    so the following assignment may lose data
      // 2. the new value may not be visible from other
      //    threads
      this.head = node.next
      node.value
    }
    else
      null
}

The standard way to fix this, as preferred by Java developers, is to use the synchronize keyword on all the Stack’s methods. You’ve seen this before, right?

public synchronized boolean isEmpty() {
    return this.head == null;
}

The synchronized keyword creates a monitor lock (also called an intrinsic lock) on the implicit this. So in case of an instance, it creates a monitor on that instance. In the case of Java’s static methods, it creates a monitor on the class object. It’s important to keep this in mind, because synchronized is not some magical tool that solves every problem you may have and I like that Scala doesn’t have such a keyword ;-)

A monitor lock is guaranteed to be acquired by only a single thread at the same time. Other threads that try acquiring it in the process are blocked until the lock is free again.

Lets improve the above using the following:

the Monitor pattern (monitor locks on this)
encapsulation of internal mutable state
Option[T] instead of nulls (Guava’s Optional<T> for the Java version), because that’s how I roll
immutable nodes for our internal linked-list

(See here for the Java version)

/**
  * Better (mutable) stack implementation.
  *
  * For type-safety, changed the interface to take a type parameter.
  */
class Stack[T] {
  /**
    * Changes:
    *
    * 1. to prevent implementation leaks, nodes in our linked-list
    *    have to be private, including the Node class
    * 2. Node instances are now immutable (always prefer immutable
    *    data structures)
    * 3. never use nulls, prefer proper initialization and Option[T]
    */
  private[this] case class Node(
    value: Option[T],
    next: Option[Node]
  )
  /**
    * The head of our stack.
    *
    * Because the Node class is private, if you make this field
    * public, then the compiler will trigger a compilation error
    */
  private[this] var head: Option[Node] = None
  def isEmpty =
    this.synchronized {
      head.isEmpty
    }
  def push(value: T): Stack[T] =
    // entering monitor lock
    this.synchronized {
      head = Some(Node(
        value = Option(value),
        next = head
      ))
      this
    }
  def pop(): Option[T] =
    // Entering monitor lock
    //
    // Note that `isEmpty` is also synchronized, but monitor locks
    // are reentrant so a lock can be acquired multiple times by the
    // same thread.
    this.synchronized {
      if (!isEmpty) {
        val node = head.get
        head = node.next
        node.value
      }
      else
        None
    }
}

That’s better. Not perfect though, as Stacks are the easiest immutable data-structures to implement … so how about not using any locks at all? (that’s for another article)

The Big Problem with Locks

Take these 2 stacks:

val stack1 = new Stack.push("World").push("Hello")
val stack2 = new Stack

Question: is the following thread safe?

while (!stack1.isEmpty)
  stack2.push( stack1.pop )

Answer: No. Given that:

A is thread safe
B is thread safe

Then using A + B is NOT thread safe, unless you make it so by using an external lock that protects both at all times.

Code that’s thread-safe through synchronization based on locks is not composable.

The Problem of Visibility

When speaking of multithreading, the most obvious problem is the inconsistency of shared mutable state when being changed and read by multiple threads at the same time. However the problem is actually twofold and the atomicity of code that changes mutable state is not your only problem.

Take this piece of code Scala code ( see here for the Java version):

var result = "Not Initialized"
var isDone = false
val producer = new Thread(new Runnable {
  def run() {
    result = "Hello, World!"
    isDone = true
  }
})
val consumer = new Thread(new Runnable {
  def run() {
    // loops until isDone is true
    while (!isDone) {}
    println(result)
  }
})
consumer.start()
producer.start()
consumer.join()

Question: What does the above print?

Hello, World!
Not initialized
Nothing, goes into an infinite loop
All of the above

The answer may surprise some of you. It’s actually number 4, all of the above. To make matters worse, you can’t predict what happens, as it depends on the CPU architecture you have, on the number of cores, on who made the VM, on what other apps you have running, on whether the laptop is plugged in or not, on planetary alignments and so on.

So what can happen?

On most desktops today, most of the time (as in >50%) it will behave as expected, which kind of sucks really, because it’s far better to have a fast and loud failure than one with subtle effects that may or may not manifest when you’re testing the app.
The JVM doesn’t guarantee that the instructions are executed in the given order. Amongst others, the VM may decide that those instructions are independent of each other and may reverse their order for things like better cache locality, or because processors are pretty smart about executing multi-cycles instructions, being able for example to start subsequent instructions before the previous ones are finished. So it’s pretty common for the compiler to reorder instructions such that longer instructions are executed before shorter ones. The processor itself may decide to execute instructions out of order, even if the VM/compiler is issuing the instructions in the right order. From the point of view of the producer thread, the result is the same as if the instructions are executed in the given order, but you can’t rely on it when viewing the results from outside threads.
The new value for isDone could be cached somewhere (like in a processor register) and the consumer thread may never see this new value. On my desktop in more than 1 out of 10 cases this little example goes into an infinite loop.

Happens-Before Relationships and Memory Barriers

As I was saying at point 2 above, in addition to cached values, you can also have reordered instructions. Say that you’ve got the following calls:

statementA;
statementB;

From the point of view of the thread executing these 2 statements, the result of statementA is available to statementB. We call this a happens-before relationship between the two statements. So from the point of view of the executing thread, the result is always the same as if these 2 statements are executing in order, even if these statements are executed in fact out of order.

Outside of the executing thread, this happens-before relationship is not guaranteed. The result of statementB could be visible to other threads, while the result of statementA could be made visible later or never.

In our example, to ensure that isDone is written after result and to ensure the visibility for outside threads for both, you need to create what is called a memory barrier.

The standard way of doing this is (again) through a monitor lock acquired on a certain object.

A synchronization block guarantees two things:

all the writes that happened on other threads on variables, by using the monitor X, are visible to our current thread if it acquired the same monitor X
at the end of the synchronization block, a memory barrier is created and changes made to variables inside that block will be visible to other threads that use the same monitor

To fix our problem with monitor locks, here’s the Scala version ( see here for the Java version):

var result = "Not Initialized"
var isDone = false
val lock = new AnyRef
val consumer = new Thread(new Runnable {
  def run() {
    var continueLooping = true
    while (continueLooping)
      lock.synchronized {
        continueLooping = !isDone
      }
    println(result)
  }
})
val producer = new Thread(new Runnable {
  def run() {
    lock.synchronized {
      result = "Hello, World!"
      isDone = true
    } // <-- memory barrier
  }
})
consumer.start()
producer.start()
consumer.join()

There is one big gotcha here. The JVM only guarantees visibility and happens-before relationships only if the threads involved in reading/writing to our variables are synchronized with the same monitor lock. This gotcha could happen for a bunch of reasons, for instance the JVM does escape-analysis and it can get rid of locks completely if it decides a lock isn’t used concurrently by multiple threads.

Volatiles

For this particular example, you actually don’t need a lock at all. All you need is a volatile:

@volatile
var isDone = false

Or in Java:

volatile boolean isDone = false;

A write to a volatile also creates a memory-barrier. If you need memory barriers, then a write to a volatile on the JVM creates a full-fence. This guarantees not only the visibility of isDone, but it also guarantees the visibility of all other variables written prior to it by the same thread, like result in our example.

Volatiles are useful sometimes in non-blocking algorithms. But even with the strong guarantee of the created memory-barrier, for most purposes where you need volatiles, you’ll end up using atomic instances from the java.util.concurrent.atomic package, like AtomicReference or AtomicInteger.

That’s because you need compare and set for non-blocking algorithms, an atomic operation that’s optimized on most CPUs today that you can’t do with plain volatiles.

But that’s a topic for another article.
